Required dependencies

npm install playwright-core
npm install @modelcontextprotocol/sdk
npm install chokidar
npm install ws
npm install @zip.js/zip.js
npm install mime
npm install jpeg-js
npm install pngjs
npm install stack-utils
npm install progress
npm install extract-zip
npm install https-proxy-agent
npm install socks-proxy-agent
npm install proper-lockfile
npm install glob
npm install rimraf

No native build steps are required for standard Node.js use. Android device support (androidServerImpl.ts) requires adb on PATH. Headful browser launches on Linux require display server libraries (install via npx playwright install-deps).

Project setup

1. Copy the source/ directory into your project, e.g. src/playwright-core/.

2. In tsconfig.json, add path aliases so internal cross-imports resolve:

{
  "compilerOptions": {
    "baseUrl": ".",
    "paths": {
      "@utils/*": ["src/playwright-core/utils/*"],
      "playwright-internal": ["src/playwright-core/index.ts"]
    },
    "module": "NodeNext",
    "moduleResolution": "NodeNext",
    "target": "ES2020",
    "esModuleInterop": true
  }
}

3. Set required environment variables before launching browsers:

PLAYWRIGHT_BROWSERS_PATH=/path/to/browsers   # override browser install dir
PLAYWRIGHT_SKIP_BROWSER_DOWNLOAD=1           # if browsers already installed
DEBUG=pw:api                                  # optional verbose API logging

4. Add a build script in package.json:

{
  "scripts": {
    "build": "tsc -p tsconfig.json",
    "start": "node dist/yourEntryPoint.js"
  }
}

5. Import from the source sub-paths as shown in the examples below.

Public API

createConnection

import { createConnection } from './tools/mcp/index';
import type { Config } from './tools/mcp/config.d';

async function createConnection(
  userConfig?: Config,
  contextGetter?: () => Promise<BrowserContext>
): Promise<Server>

Creates an MCP Server instance backed by a Playwright browser. Pass an optional Config to control browser type, isolation, and context options. Pass contextGetter to supply your own BrowserContext instead of launching a new browser. Use this when integrating Playwright with an AI agent framework that speaks the Model Context Protocol.

createPlaywright

import { createPlaywright } from './server/playwright';

function createPlaywright(options: { sdkLanguage: string; isServer?: boolean }): Playwright

Instantiates the server-side Playwright object that owns chromium, firefox, and webkit browser type instances. This is the root server object — use it when building a custom in-process browser server or a bespoke remote transport layer.

ServerRegistry (from serverRegistry.ts)

import { ServerRegistry, BrowserDescriptor, BrowserStatus } from './serverRegistry';

class ServerRegistry extends EventEmitter {
  list(): BrowserStatus[]
  register(descriptor: BrowserDescriptor): string      // returns guid
  unregister(guid: string): void
  on(event: 'added',   listener: (d: BrowserDescriptor) => void): this
  on(event: 'removed', listener: (guid: string) => void): this
  on(event: 'changed', listener: (d: BrowserDescriptor) => void): this
}

Tracks running browser server endpoints discovered from the filesystem via chokidar. Use it in a dashboard or proxy server to enumerate connectable browser instances without hardcoding endpoints.

filteredTools / browserTools

import { filteredTools, browserTools } from './tools/backend/tools';
import type { FullConfig } from './tools/mcp/config';

function browserTools(): Tool[]
function filteredTools(config: FullConfig): Tool[]

Returns the list of MCP tool descriptors Playwright exposes (click, navigate, screenshot, etc.). filteredTools trims the list according to the resolved config (e.g., removing snapshot tools when vision mode is on). Use these when you need to advertise tool schemas to an MCP client.

Working examples

Scenario - Launch an MCP server for an AI agent

An AI agent framework that speaks the Model Context Protocol can connect to this server and issue browser actions as structured tool calls.

import { createConnection } from './source/tools/mcp/index';

async function main() {
  const server = await createConnection({
    browser: {
      browserName: 'chromium',
      isolated: true,
      launchOptions: { headless: true },
      contextOptions: { viewport: { width: 1280, height: 720 } },
    },
  });

  // server is an @modelcontextprotocol/sdk Server
  // wire it to a transport (stdio, WebSocket, etc.)
  const { StdioServerTransport } = await import('@modelcontextprotocol/sdk/server/stdio.js');
  await server.connect(new StdioServerTransport());
  console.log('MCP browser server ready on stdio');
}

main().catch(console.error);

Scenario - Use ServerRegistry to list running browser endpoints

A dashboard process watches the filesystem for descriptors written by other Playwright server processes and emits events when browsers come and go.

import { ServerRegistry } from './source/serverRegistry';
import type { BrowserDescriptor, BrowserStatus } from './source/serverRegistry';

const registry = new ServerRegistry();

registry.on('added', (descriptor: BrowserDescriptor) => {
  console.log('Browser connected:', descriptor.browser.browserName, descriptor.endpoint);
});

registry.on('removed', (guid: string) => {
  console.log('Browser disconnected:', guid);
});

const browsers: BrowserStatus[] = registry.list();
console.log('Currently available browsers:', browsers.length);

Scenario - Create an in-process Playwright server and open a page

Use the server-layer directly (no subprocess) to create a browser, open a page, and capture a screenshot.

import { createPlaywright } from './source/server/playwright';
import { nullProgress } from './source/server/progress';

async function screenshot(url: string, outputPath: string) {
  const playwright = createPlaywright({ sdkLanguage: 'javascript' });
  const browserType = playwright.chromium;

  const browser = await browserType.launch({ headless: true });
  const context = await browser.newContext();
  const page = await context.newPage();

  await page.mainFrame().goto(nullProgress(), url, { waitUntil: 'load', timeout: 30000 });
  await page.screenshot({ path: outputPath, type: 'png' });

  await browser.close();
  console.log('Screenshot saved to', outputPath);
}

screenshot('https://playwright.dev', '/tmp/pw.png').catch(console.error);

File walkthrough

• cli/ - Houses the program.ts Commander CLI definition, driver.ts for the in-process driver loop, browserActions.ts for record/codegen helpers, and installActions.ts for browser download commands.
• client/ - All public-facing wrapper classes that talk over the channel protocol to the server. connection.ts owns the IPC loop; channelOwner.ts is the base class for every remote object.
• entry/ - Minimal process entry files; each one imports and wires a single feature (MCP, daemon, dashboard, browser download) so the bundle can be split cleanly.
• protocol/ - JSON-schema-style validators for every message type on the wire, plus serializers for complex types (errors, handles, routes).
• remote/ - Server-side transports: pipe, WebSocket, and connection-management logic that maps incoming IPC sessions to PlaywrightConnection instances.
• server/ - The authoritative in-process implementation: Browser, BrowserContext, Page, Frame, Network, CDP dispatchers, and the trace viewer server.
• tools/ - MCP tool implementations (click, type, screenshot, navigate, etc.), the browser backend abstraction, CLI client/daemon programs, and the trace parser used by the viewer.
• androidServerImpl.ts - Bridges the Android device ADB layer into the standard server dispatcher API.
• bootstrap.ts - Runs early-process initialization (signal handlers, unhandled rejection setup) before any other module loads.
• browserServerImpl.ts - Implements the out-of-process browser server lifecycle, writing endpoint descriptors to disk.
• coreBundle.ts - Single re-export barrel for downstream bundlers that want the whole library surface in one chunk.
• inprocess.ts / outofprocess.ts - Two factory entry points: one creates Playwright in the same process, the other spawns a child process and connects over a pipe.
• package.ts - Exposes packageRoot, binPath, and packageJSON so the rest of the codebase can reference install-time paths without hardcoding.
• serverRegistry.ts - ServerRegistry watches a well-known directory for JSON descriptor files written by browser server processes, emitting typed events.
• utilsBundle.ts - Re-exports shared utilities (crypto, env, file, network, etc.) from the internal @utils alias so they can be bundled together.

Common pitfalls and fixes

• Cannot find module '@utils/...' — The source uses TypeScript path aliases. Add "@utils/*": ["src/playwright-core/utils/*"] to tsconfig.json paths and ensure tsc (not just ts-node) resolves them; for ts-node add tsconfig-paths/register.
• Browsers not found at runtime — Set PLAYWRIGHT_BROWSERS_PATH to the directory populated by npx playwright install, or call npx playwright install chromium before starting your process.
• ESM/CJS interop errors with @modelcontextprotocol/sdk — The SDK ships ESM-only. Set "module": "NodeNext" and "moduleResolution": "NodeNext" in tsconfig.json, and add "type": "module" to your package.json.
• chokidar ENOSPC on Linux — Increase the inotify limit: echo fs.inotify.max_user_watches=524288 | sudo tee -a /etc/sysctl.conf && sudo sysctl -p.
• nullProgress not exported from a clean import — Import it explicitly from source/server/progress, not from the top-level barrel, to avoid circular dependency issues during tree-shaking.
• Android support fails silently — androidServerImpl.ts requires adb on PATH and USB debugging enabled on the device. Verify with adb devices before calling any Android APIs.

Vibe-coding prompt template

I have dropped the playwright-core source (playwright-internal@1.60.0-next) into
my project at `src/playwright-core/`. I also have `USAGE.md` in the project root
describing every exported symbol, directory layout, required dependencies, and
tsconfig setup.

Please integrate this source into my project step by step:

1. Read `USAGE.md` sections "Required dependencies", "Project setup", and
   "Public API" first.
2. Install all dependencies listed in "Required dependencies".
3. Update my `tsconfig.json` with the path aliases from "Project setup".
4. Create `src/browserService.ts` that:
   - Uses `createConnection` from `src/playwright-core/tools/mcp/index.ts` to
     start an MCP server backed by headless Chromium.
   - Connects it to a stdio transport from `@modelcontextprotocol/sdk`.
   - Exports a `startBrowserService()` async function.
5. Create `src/registry.ts` that imports `ServerRegistry` from
   `src/playwright-core/serverRegistry.ts`, instantiates it, logs every
   `added` and `removed` event, and exports a `getRegistry()` singleton.
6. Wire both into `src/index.ts` and add a `start` npm script.
7. Show me the final file tree and any remaining manual steps.

Only use symbols documented in `USAGE.md`. Do not invent new APIs.

License and credit

Playwright is released under the Apache License 2.0. See source/LICENSE if present, or refer to the official repository. Upstream package: user@example.com by Microsoft Corporation.

This product’s unique contribution is clean room implementation of valuable code block into AVCP compatible standard.

The full install guide and integration prompts unlock after purchase.
