Native modules: better-sqlite3 requires a native build. After npm install, run:

./node_modules/.bin/electron-rebuild -f -w better-sqlite3

This must be repeated any time the Electron version changes.

Project setup

1. Copy the contents of source/ into your project root or a subdirectory (e.g., ./mailspring-app/).

2. From the directory containing package.json (the copied source/), install dependencies:

   npm install


3. Wire tsconfig.json path aliases. The root tsconfig.json maps mailspring-exports and mailspring-component-kit to internal source paths. Verify these paths entries resolve correctly relative to your project root:

   {
     "compilerOptions": {
       "baseUrl": ".",
       "paths": {
         "mailspring-exports": ["src/mailspring-exports.ts"],
         "mailspring-component-kit": ["src/mailspring-component-kit.ts"]
       }
     }
   }


4. Required environment variables for the Electron main process:

   MAILSPRING_DISABLE_GPU=1          # optional, headless CI
   ELECTRON_ENABLE_LOGGING=1         # optional, verbose renderer logs


5. Start the app from the source root:

   npm start


6. To build a distributable:

   npm run build


Public API

activate / deactivate (plugin lifecycle)

export function activate(state?: any): void;
export function deactivate(state?: any): void;

Every internal package exports these two functions. activate is called by the package manager when the plugin is loaded; deactivate is called on teardown. Use activate to register components and extensions, and deactivate to unregister them so the app can hot-reload plugins cleanly.

ComponentRegistry.register / unregister

// From mailspring-exports
ComponentRegistry.register(ComponentClass: React.ComponentType, descriptor: {
  location?: WorkspaceStore.Location | WorkspaceStore.Location,
  role?: string,
}): void;

ComponentRegistry.unregister(ComponentClass: React.ComponentType): void;

Mounts a React component into a named layout location (e.g., WorkspaceStore.Location.RootSidebar) or into a named role slot (e.g., { role: 'MessageAttachments' }). Use register in activate and always pair it with unregister in deactivate to avoid duplicate renders.

ExtensionRegistry.AccountSidebar.register

// From mailspring-exports
ExtensionRegistry.AccountSidebar.register(extension: {
  name: string;
  sidebarItem(accountIds: string[]): {
    id: string;
    name: string;
    iconName: string;
    perspective: MailboxPerspective;
  };
}): void;

Adds a custom item to the account sidebar navigation. The sidebarItem callback receives the current account IDs and must return a descriptor including a MailboxPerspective instance that controls what thread list content is shown when the item is selected. Used by the Activity, Send Later, Snooze, and similar packages.

Working examples

Scenario - Registering a custom sidebar component

Add a React component to the root sidebar layout location. This mirrors the exact pattern used by account-sidebar/lib/main.ts.

import { ComponentRegistry, WorkspaceStore } from 'mailspring-exports';
import MyCustomSidebar from './components/my-custom-sidebar';

export function activate(state: any) {
  ComponentRegistry.register(MyCustomSidebar, {
    location: WorkspaceStore.Location.RootSidebar,
  });
}

export function deactivate(state: any) {
  ComponentRegistry.unregister(MyCustomSidebar);
}

Scenario - Adding a navigation item to the account sidebar

Register an extension that provides a custom mailbox perspective and sidebar entry, following the pattern in activity/lib/main.ts.

import {
  localized,
  ExtensionRegistry,
  WorkspaceStore,
  ComponentRegistry,
  MailboxPerspective,
} from 'mailspring-exports';
import MyView from './components/my-view';

class MyPerspective extends MailboxPerspective {
  sheet() { return WorkspaceStore.Sheet.MyView; }
  threads() { return null; }
  canReceiveThreadsFromAccountIds() { return false; }
  unreadCount() { return 0; }
}

const MySidebarExtension = {
  name: 'MyFeature',
  sidebarItem(accountIds: string[]) {
    return {
      id: 'MyFeature',
      name: localized('My Feature'),
      iconName: 'my-feature.png',
      perspective: new MyPerspective(accountIds),
    };
  },
};

export function activate() {
  ExtensionRegistry.AccountSidebar.register(MySidebarExtension);
  WorkspaceStore.defineSheet('MyView', { root: true }, { list: ['RootSidebar', 'MyContent'] });
  ComponentRegistry.register(MyView, { location: WorkspaceStore.Location.MyContent });
}

export function deactivate() {
  ExtensionRegistry.AccountSidebar.unregister(MySidebarExtension);
  ComponentRegistry.unregister(MyView);
}

Scenario - Adding a preferences tab

Register a new tab in the Preferences window, mirroring category-mapper/lib/main.ts.

import { localized, PreferencesUIStore } from 'mailspring-exports';

let preferencesTab: any;

export function activate() {
  preferencesTab = new PreferencesUIStore.TabItem({
    tabId: 'MySettings',
    displayName: localized('My Settings'),
    componentClassFn: () => require('./my-preferences-panel').default,
  });
  PreferencesUIStore.registerPreferencesTab(preferencesTab);
}

export function deactivate() {
  PreferencesUIStore.unregisterPreferencesTab(preferencesTab.sectionId);
}

File walkthrough

• src/ - Application core: Electron main/renderer bootstrap, mailspring-exports barrel, flux stores (WorkspaceStore, Actions, ComponentRegistry, etc.), and the package loader that calls activate/deactivate on each plugin.
• internal_packages/ - Self-contained feature plugins. Each has a package.json, a lib/main.ts with activate/deactivate, and optional styles/ and assets/ subdirectories.
• internal_packages_disabled/ - Plugins excluded from the default build; copy to internal_packages/ to enable.
• keymaps/ - CSON/JSON keymap files binding key combinations to named Mailspring commands.
• lang/ - JSON localization files keyed by locale code; strings are accessed via localized().
• menus/ - Platform-specific menu definition files consumed by the Electron main process.
• script/ - Node.js scripts for building, signing, and publishing releases; not imported at runtime.
• static/ - Bundled assets referenced by CSS and components: icons, default themes, fonts.
• dot-mailspring/ - Template for the user's ~/.mailspring directory, including default config.json and keymap.json.
• package.json - Defines user@example.com, scripts (start, build, test), and all dependencies.
• tsconfig.json - Strict TypeScript config with path aliases for mailspring-exports and mailspring-component-kit.
• result-counter.js - CLI utility that parses test runner output and summarizes pass/fail counts.

Common pitfalls and fixes

• better-sqlite3 crashes after Electron version change: Run ./node_modules/.bin/electron-rebuild -f -w better-sqlite3 to recompile the native addon against the new Electron headers.
• mailspring-exports module not found: Ensure tsconfig.json paths and your bundler alias config both map mailspring-exports to src/mailspring-exports.ts; Webpack/esbuild require a separate alias entry independent of TypeScript paths.
• Plugin activate called with wrong this: The package loader binds this to the plugin module object (used in category-mapper). If you port a plugin to a class, replace this.preferencesTab with a module-level variable to avoid binding issues.
• localized() returns raw key string: The lang/ directory must be loaded before any plugin activates. If you start the renderer in isolation (e.g., Storybook), mock localized as (s: string) => s.
• WorkspaceStore.Sheet.X is undefined at activate time: defineSheet must be called before any component references WorkspaceStore.Sheet.X. Call defineSheet at the top of activate, not in a deferred callback.
• ESM/CJS interop with require() in componentClassFn: PreferencesUIStore.TabItem's componentClassFn uses a lazy require() call. Under ESM builds this will fail; wrap it with createRequire(import.meta.url) or convert the tab panel to a static import.

Vibe-coding prompt template

I have purchased the Mailspring Electron App Source block. The source is in the
`source/` directory of this project. There is also a `USAGE.md` file with real
API signatures, working code examples, and setup instructions.

The upstream npm package is `user@example.com` and the core import path
for framework APIs is `mailspring-exports`.

Please help me integrate this source into my existing Electron/TypeScript project
by doing the following steps:

1. Read `USAGE.md` fully before writing any code.
2. Identify which internal_packages I need for my feature: [DESCRIBE YOUR FEATURE].
3. Wire the tsconfig.json path aliases for `mailspring-exports` and
   `mailspring-component-kit` into my project's tsconfig.
4. Create a new plugin under `source/internal_packages/my-plugin/` with a
   `lib/main.ts` that exports `activate` and `deactivate`, using only symbols
   visible in `USAGE.md`'s Public API section.
5. Register my component using `ComponentRegistry.register` in `activate` and
   unregister it in `deactivate`.
6. If I need a sidebar entry, use `ExtensionRegistry.AccountSidebar.register`
   with a `MailboxPerspective` subclass as shown in `USAGE.md`.
7. Show me any native rebuild commands needed for `better-sqlite3`.
8. Do not invent any API symbols not present in `USAGE.md`.

License and credit

Mailspring is released under the GNU General Public License v3.0 (GPLv3). See source/LICENSE if present, or refer to the official repository for the full license text. The upstream package is user@example.com, maintained by Foundry376. Any derivative work that distributes the GPLv3-licensed source must also be released under GPLv3.

This product’s unique contribution is clean room implementation of valuable code block into AVCP compatible standard.

The full install guide and integration prompts unlock after purchase.
