Required dependencies

npm install compare-version sqlite3 fs-extra @electron/remote
npm install react react-redux redux
npm install @joplin/lib @joplin/utils @joplin/renderer
npm install electron   # for desktop integration
npm install react-native  # for mobile integration only

Native/additional build steps:

• SQLite3: requires native compilation. Run npm rebuild sqlite3 or use better-sqlite3 with the correct binding for your Node version.
• sharp (optional, CLI): npm install sharp — if absent, a warning is printed but the CLI still runs.
• iOS: cd ios && pod install after adding React Native packages.
• Android: standard ./gradlew linking; react-native-saf-x and react-native-alarm-notification require npx react-native link or manual build.gradle edits.
• Electron: version must match what app-desktop/package.json specifies to avoid native module ABI mismatch.

Project setup

1. Copy the source/ directory into your project root, e.g. ./joplin-packages/.
2. Add path mappings in tsconfig.json:

   {
     "compilerOptions": {
       "paths": {
         "@joplin/lib/*": ["./joplin-packages/lib/*"],
         "@joplin/utils/*": ["./joplin-packages/utils/*"],
         "@joplin/renderer/*": ["./joplin-packages/renderer/*"]
       }
     }
   }


3. If using webpack or esbuild, add matching alias entries pointing to the same directories.
4. Initialize the SQLite database and shim before importing any model:

   import FsDriverNode from './joplin-packages/lib/fs-driver-node';
   import shim from './joplin-packages/lib/shim';
   // call shimInitNode or shimInitCli before any model usage


5. Set environment variables:

   NODE_ENV=production   # or 'dev' for dev app IDs
   JOPLIN_PROFILE_DIR=/path/to/profile   # where settings/db are stored


6. For the server package, configure JOPLIN_BASE_URL, DB_CLIENT (pg or sqlite3), and MAILER_* vars as documented in server/.

Public API

app (app-cli default export)

// app-cli/app/app.ts
import app from './app';
// app is a singleton Application instance
app.start(argv: string[]): Promise<void>;

The CLI application singleton. Call app.start(process.argv) to boot the REPL, load the database, and register all commands. Used as the entry point in main.js.

ElectronAppWrapper (app-desktop)

// app-desktop/ElectronAppWrapper.ts
import ElectronAppWrapper from './ElectronAppWrapper';
new ElectronAppWrapper(env: string, profileDir: string, isDebugMode: boolean): ElectronAppWrapper;
ElectronAppWrapper.prototype.start(): Promise<void>;

Wraps Electron's app lifecycle: creates the BrowserWindow, registers IPC handlers, and wires the bridge. Instantiated in main.ts after profile directory setup.

Desktop command index

// app-desktop/commands/index.ts
import commands from './commands/index';
// commands: any[]  — array of command module namespaces
// Each module exports: { execute(context): Promise<void>, declaration(): CommandDeclaration }

Auto-generated barrel of all desktop commands (copy, export, profile switching, external editor, etc.). Pass the array to the command service's registerCommands method to make them available via the command palette.

Working examples

Scenario - Boot the CLI application

Embed the Joplin CLI inside a custom Node.js process, overriding the profile directory.

import FsDriverNode from './joplin-packages/lib/fs-driver-node';
import Logger from './joplin-packages/utils/Logger';
import app from './joplin-packages/app-cli/app/app';
import shimInitCli from './joplin-packages/app-cli/app/utils/shimInitCli';

async function main() {
  const fsDriver = new FsDriverNode();
  Logger.fsDriver_ = fsDriver;

  await shimInitCli.default();

  // Override argv to set a custom profile
  const argv = ['node', 'main.js', '--profile', '/tmp/my-joplin-profile'];
  await app.default.start(argv);
}

main().catch(console.error);

Scenario - Register desktop commands in an Electron renderer

Load all built-in desktop commands and register them with a command service stub.

import commands from './joplin-packages/app-desktop/commands/index';

interface CommandDeclaration { name: string; label: string; }
interface CommandModule {
  declaration(): CommandDeclaration;
  execute(context: unknown): Promise<void>;
}

function registerCommands(mods: CommandModule[], context: unknown) {
  for (const mod of mods) {
    const decl = mod.declaration();
    console.log(`Registering command: ${decl.name}`);
    // wire into your command palette / IPC handler
  }
}

registerCommands(commands as CommandModule[], { /* app context */ });

Scenario - Initialise the Electron main process wrapper

Start the desktop Electron application with a custom profile path.

// my-electron-main.ts
import { app as electronApp } from 'electron';
import ElectronAppWrapper from './joplin-packages/app-desktop/ElectronAppWrapper';
import FsDriverNode from './joplin-packages/lib/fs-driver-node';
import Logger from './joplin-packages/utils/Logger';

Logger.fsDriver_ = new FsDriverNode();

electronApp.whenReady().then(async () => {
  const wrapper = new ElectronAppWrapper(
    'prod',           // env
    '/home/user/.config/my-joplin',  // profile dir
    false             // debug mode
  );
  await wrapper.start();
});

File walkthrough

• app-cli/ - Self-contained terminal client; app/app.ts is the singleton, app/main.js is the Node entry point that wires models and shim before handing off to app.start().
• app-clipper/ - Browser extension; content_scripts/index.js scrapes page DOM and popup/src/index.js provides the Redux-powered popup UI.
• app-desktop/ - Electron app; main.ts bootstraps the main process, ElectronAppWrapper manages window lifecycle, commands/index.ts is the auto-generated command barrel.
• app-mobile/ - React Native app for iOS/Android; contains native module bridges and RN-specific shim implementations.
• default-plugins/ - Pre-built plugin bundles copied into desktop distributions at build time.
• editor/ - CodeMirror 6 wrapper component used by both desktop and mobile editors.
• fork-htmlparser2/, fork-sax/, fork-uslug/ - Vendored and patched third-party parsers; import from here instead of upstream packages.
• lib/ - The heart of Joplin: ORM models (Note, Folder, Resource, etc.), sync engine, e2ee services, settings, and the platform shim interface.
• renderer/ - Converts Markdown to HTML with plugin support (math, diagrams, syntax highlighting); safe to use in Node or browser contexts.
• server/ - Express/Koa API server for self-hosted sync; has its own docker-compose setup and migration system.
• utils/ - Lightweight utilities (Logger, type helpers) shared across all packages with zero heavy dependencies.
• turndown/ + turndown-plugin-gfm/ - HTML→Markdown pipeline used by the web clipper and importer.

Common pitfalls and fixes

• SQLite3 ABI mismatch: native binding compiled for wrong Node/Electron version — run npm rebuild sqlite3 --runtime=electron --target=<version> --dist-url=https://electronjs.org/headers.
• Circular dependency crash at startup: BaseItem.loadClass(...) calls must happen before any model is first accessed — copy the block from app-cli/app/main.js verbatim.
• ESM/CJS interop: several sub-packages use "type": "module" — if bundling with esbuild add --format=cjs or use dynamic import() at call sites.
• sharp not found warning flooding stdout: wrap require('sharp') in a try/catch and swallow the error as shown in main.js; the app remains functional.
• Profile directory not created: mkdirpSync(rootProfileDir) must be called before Setting.load() — missing this causes a silent DB open failure.
• React version conflict between packages: app-desktop and app-mobile may pin different React majors — hoist a single version in your root package.json resolutions field.

Vibe-coding prompt template

I have the Joplin monorepo packages available under `./source/` and the
integration guide at `./USAGE.md`. The upstream package is `joplin` (domain:
backend), source root `packages/`.

Please help me integrate the following into my existing Node.js/TypeScript
project step by step:

1. Read USAGE.md fully before writing any code.
2. Set up tsconfig paths and module aliases so that `@joplin/lib`,
   `@joplin/utils`, and `@joplin/renderer` resolve to `./source/lib`,
   `./source/utils`, and `./source/renderer` respectively.
3. Wire the FsDriverNode shim and Logger as shown in
   `source/app-cli/app/main.js` before any model is imported.
4. Initialize the SQLite database and load Settings using the patterns
   in `source/lib/`.
5. [Describe your specific feature here — e.g., "render a Markdown note
   to HTML using source/renderer", "sync notes to a Joplin Server instance",
   "import an Evernote ENEX file"].
6. Show the complete, runnable TypeScript code with real imports from
   `./source/` only. Do not invent exports not present in USAGE.md.

License and credit

Joplin is released under the MIT License. See source/ root or the upstream repository for the full license text.

Upstream project: https://github.com/laurent22/joplin
Upstream npm scope: @joplin/* (individual packages published separately under this scope).

This product’s unique contribution is clean room implementation of valuable code block into AVCP compatible standard.

The full install guide and integration prompts unlock after purchase.
