import '@xyflow/react/dist/style.css';

If consuming raw source instead of the npm package, point to src/react-flow/styles/ and include the CSS via your bundler.

Public API

ReactFlow

import ReactFlow from './container/ReactFlow';

// Core props (simplified)
type ReactFlowProps<NodeType, EdgeType> = {
  nodes: NodeType[];
  edges: EdgeType[];
  onNodesChange?: (changes: NodeChange[]) => void;
  onEdgesChange?: (changes: EdgeChange[]) => void;
  onConnect?: (connection: Connection) => void;
  fitView?: boolean;
  nodeTypes?: Record<string, ComponentType>;
  edgeTypes?: Record<string, ComponentType>;
};

The root component. Mount it inside a sized container (explicit width/height or 100%). Pass controlled nodes and edges arrays and wire up change handlers with useNodesState/useEdgesState.

useReactFlow

import { useReactFlow } from './hooks/useReactFlow';

function useReactFlow<NodeType, EdgeType>(): {
  getNodes(): NodeType[];
  getEdges(): EdgeType[];
  setNodes(nodes: NodeType[]): void;
  setEdges(edges: EdgeType[]): void;
  fitView(options?: FitViewOptions): void;
  zoomIn(): void;
  zoomOut(): void;
  getZoom(): number;
  // ...additional methods
};

Use inside any component rendered under ReactFlow or ReactFlowProvider to programmatically read or mutate graph state without prop drilling.

useNodesState / useEdgesState

import { useNodesState, useEdgesState } from './hooks/useNodesEdgesState';

function useNodesState<T>(initialNodes: Node<T>[]): [Node<T>[], Dispatch<SetStateAction<Node<T>[]>>, (changes: NodeChange[]) => void];
function useEdgesState<T>(initialEdges: Edge<T>[]): [Edge<T>[], Dispatch<SetStateAction<Edge<T>[]>>, (changes: EdgeChange[]) => void];

Convenience hooks that own local node/edge state and return a compatible onNodesChange/onEdgesChange handler. Pass the three return values directly to ReactFlow. Use when you do not need an external state manager.

applyNodeChanges / applyEdgeChanges

import { applyNodeChanges, applyEdgeChanges } from './utils/changes';

function applyNodeChanges(changes: NodeChange[], nodes: Node[]): Node[];
function applyEdgeChanges(changes: EdgeChange[], edges: Edge[]): Edge[];

Pure functions for manually applying change events to node/edge arrays. Use inside a Redux reducer, Zustand action, or any custom state layer as a drop-in replacement for the built-in useNodesState handler.

Background

import { Background, BackgroundVariant, type BackgroundProps } from './additional-components/Background';

// BackgroundVariant enum
enum BackgroundVariant { Dots = 'dots', Lines = 'lines', Cross = 'cross' }

Renders a tiled SVG background pattern inside the canvas. Place it as a child of ReactFlow.

Working examples

Scenario - Minimal controlled flow

A basic two-node, one-edge diagram with built-in state management.

import React, { useCallback } from 'react';
import ReactFlow, { useNodesState, useEdgesState, addEdge, Background, Controls } from './index';
import type { Connection } from './types';
import '@xyflow/react/dist/style.css';

const init_nodes = [
  { id: '1', position: { x: 0, y: 0 }, data: { label: 'Node 1' } },
  { id: '2', position: { x: 0, y: 120 }, data: { label: 'Node 2' } },
];
const init_edges = [{ id: 'e1-2', source: '1', target: '2' }];

export default function MinimalFlow() {
  const [nodes, setNodes, onNodesChange] = useNodesState(init_nodes);
  const [edges, setEdges, onEdgesChange] = useEdgesState(init_edges);

  const onConnect = useCallback(
    (params: Connection) => setEdges((eds) => addEdge(params, eds)),
    [setEdges],
  );

  return (
    <div style={{ width: '100vw', height: '100vh' }}>
      <ReactFlow
        nodes={nodes}
        edges={edges}
        onNodesChange={onNodesChange}
        onEdgesChange={onEdgesChange}
        onConnect={onConnect}
        fitView
      >
        <Background variant={BackgroundVariant.Dots} />
        <Controls />
      </ReactFlow>
    </div>
  );
}

Scenario - Programmatic viewport control with useReactFlow

Fit the view or zoom to a specific node on button click from a panel inside the canvas.

import React from 'react';
import ReactFlow, { Panel, useReactFlow, useNodesState, useEdgesState } from './index';

function ControlPanel() {
  const { fitView, zoomIn, zoomOut, getZoom } = useReactFlow();
  return (
    <Panel position="top-right">
      <button onClick={() => fitView({ duration: 400 })}>Fit View</button>
      <button onClick={() => zoomIn({ duration: 200 })}>+</button>
      <button onClick={() => zoomOut({ duration: 200 })}>-</button>
      <span>Zoom: {getZoom().toFixed(2)}</span>
    </Panel>
  );
}

export default function ProgrammaticFlow() {
  const [nodes, , onNodesChange] = useNodesState([
    { id: 'a', position: { x: 100, y: 100 }, data: { label: 'A' } },
  ]);
  const [edges, , onEdgesChange] = useEdgesState([]);

  return (
    <div style={{ width: 800, height: 600 }}>
      <ReactFlow nodes={nodes} edges={edges} onNodesChange={onNodesChange} onEdgesChange={onEdgesChange}>
        <ControlPanel />
      </ReactFlow>
    </div>
  );
}

Scenario - External state with applyNodeChanges

Integrate flow changes into a Zustand store outside React Flow's own state system.

import { create } from 'zustand';
import { applyNodeChanges, applyEdgeChanges } from './utils/changes';
import type { Node, Edge, NodeChange, EdgeChange } from './types';

interface FlowStore {
  nodes: Node[];
  edges: Edge[];
  onNodesChange: (changes: NodeChange[]) => void;
  onEdgesChange: (changes: EdgeChange[]) => void;
}

export const useFlowStore = create<FlowStore>((set) => ({
  nodes: [{ id: '1', position: { x: 50, y: 50 }, data: { label: 'Start' } }],
  edges: [],
  onNodesChange: (changes) =>
    set((state) => ({ nodes: applyNodeChanges(changes, state.nodes) })),
  onEdgesChange: (changes) =>
    set((state) => ({ edges: applyEdgeChanges(changes, state.edges) })),
}));

File walkthrough

• container/ - Mounts the SVG/HTML canvas, wires the Zustand store, composes all internal sub-renderers.
• components/ - Individual rendering units: EdgeWrapper, NodeWrapper, Handle, ConnectionLine, Panel, UserSelection, NodesSelection, EdgeLabelRenderer, ViewportPortal, BatchProvider, StoreUpdater, SelectionListener, ReactFlowProvider, A11yDescriptions, Attribution.
• additional-components/ - Optional UI overlays bundled separately: Background patterns, zoom/fit Controls, MiniMap, NodeResizer, NodeToolbar, EdgeToolbar.
• hooks/ - Public React hooks that subscribe to the Zustand store: useReactFlow, useNodes, useEdges, useViewport, useKeyPress, useStore, useHandleConnections, useNodesData, useConnection, etc.
• store/ - Zustand store factory, selectors, and action creators used internally.
• contexts/ - React contexts, notably NodeIdContext (exposes the current node's id to child components).
• types/ - All exported TypeScript interfaces and types (Node, Edge, Connection, Viewport, change event types, etc.).
• utils/ - Pure utility functions: applyNodeChanges, applyEdgeChanges, isNode, isEdge, path calculators.
• styles/ - Base stylesheet that must be loaded for correct layout.
• index.ts - Single barrel file re-exporting the entire public API.
• custom.d.ts - Ambient module declarations for non-TS assets.

Common pitfalls and fixes

• Unsized container: ReactFlow renders at 0x0 if the parent has no explicit size. Fix: give the wrapper width: 100%; height: 100vh (or any non-zero dimensions).
• Missing stylesheet: Nodes and edges appear misaligned or invisible without the base CSS. Fix: import '@xyflow/react/dist/style.css' exactly once at app root.
• useReactFlow outside provider: Calling the hook outside a ReactFlow tree throws. Fix: wrap the subtree in <ReactFlowProvider> when access is needed above the canvas.
• Stale node positions after programmatic update: Forgetting to call updateNodeInternals after changing a node's handle count causes misaligned edges. Fix: call useUpdateNodeInternals with the affected node id after the change.
• ESM/CJS interop in Jest/Vitest: The package ships ESM; older Jest configs fail to transform it. Fix: add @xyflow/react to transformIgnorePatterns exclusions and enable ESM mode in Jest config.
• addEdge not imported: It is a system-level re-export from @xyflow/system, not directly in this source tree. Fix: import it from the npm package @xyflow/react or add the system package and re-export it alongside this source.

Vibe-coding prompt template

I have a copy of the React Flow source in `src/react-flow/` and a USAGE.md
explaining its API. The upstream package is `@xyflow/react` (xyflow monorepo).

Please integrate React Flow into my project step-by-step:

1. Read `USAGE.md` and `src/react-flow/index.ts` for the full export surface.
2. Install all required peer dependencies listed in USAGE.md.
3. Import the base stylesheet once at my app entry point.
4. Create a new component at `src/components/FlowCanvas.tsx` that:
   - Uses `useNodesState` and `useEdgesState` for controlled state.
   - Renders `<ReactFlow>` inside a full-screen div.
   - Includes `<Background>`, `<Controls>`, and `<MiniMap>` as children.
   - Exposes an `onConnect` callback using `addEdge`.
5. Wrap the relevant part of my app with `<ReactFlowProvider>` where needed.
6. Show me where to call `applyNodeChanges` / `applyEdgeChanges` if I want
   to move state into my existing Zustand store.
7. Point out any tsconfig or bundler changes required.

Use only exports visible in `src/react-flow/index.ts`. Do not invent APIs.

License and credit

React Flow is released under the MIT License. See source/LICENSE if present, or the upstream repository at https://github.com/xyflow/xyflow. The npm package is published as @xyflow/react. Commercial use inside revenue-generating products is permitted under MIT but the authors request sponsorship via React Flow Pro or GitHub Sponsors.
