No native modules, pod installs, or Android linking steps are required. This is a pure TypeScript/React package.

Project setup

1. Copy the source/ directory into your project root, for example at src/graphweaver/.

2. Add path aliases to tsconfig.json so TypeScript resolves internal cross-package imports:

{
  "compilerOptions": {
    "baseUrl": ".",
    "paths": {
      "@graphweaver/admin-ui/*": ["src/graphweaver/admin-ui/src/*"],
      "@graphweaver/admin-ui-components/*": ["src/graphweaver/admin-ui-components/src/*"]
    },
    "jsx": "react-jsx",
    "module": "ESNext",
    "moduleResolution": "bundler",
    "strict": true
  }
}

3. Mirror the same aliases in vite.config.ts:

import { defineConfig } from 'vite';
import react from '@vitejs/plugin-react';
import { resolve } from 'path';

export default defineConfig({
  plugins: [react()],
  resolve: {
    alias: {
      '@graphweaver/admin-ui': resolve(__dirname, 'src/graphweaver/admin-ui/src'),
    },
  },
});

4. Set any required environment variables in a .env file at project root:

VITE_API_URL=http://localhost:3000/graphql

5. Use src/graphweaver/admin-ui/src/main.tsx as the entry point for the Admin UI SPA, or import individual page components into an existing router.

Public API

AnalyticsPage

// exported from admin-ui/src/pages/analytics/component.tsx
// re-exported via admin-ui/src/pages/analytics/index.ts
// and admin-ui/src/pages/index.ts
export { AnalyticsPage } from './pages/analytics';

A React component that renders the analytics dashboard page. Use it when you want to mount the analytics view at a specific route in an existing React Router setup. It queries usage statistics from the Graphweaver GraphQL API through the Apollo Client context.

ListPage

// exported from admin-ui/src/pages/list/component.tsx
// re-exported via admin-ui/src/pages/list/index.ts
// and admin-ui/src/pages/index.ts
export { ListPage } from './pages/list';

A React component that renders a paginated, filterable entity list for a given GraphQL type. Use it as the primary data browsing view for any registered Graphweaver entity. It reads the current entity from the router context and issues list queries automatically.

PlaygroundPage

// exported from admin-ui/src/pages/playground/component.tsx
// re-exported via admin-ui/src/pages/playground/index.ts
// and admin-ui/src/pages/index.ts
export { PlaygroundPage } from './pages/playground';

A React component that embeds an interactive GraphQL Playground (or compatible IDE) pointed at the configured API endpoint. Use it to provide developers and admins with an in-browser query editor within the Admin UI.

RootPage

// exported from admin-ui/src/pages/root/component.tsx
// re-exported via admin-ui/src/pages/root/index.ts
// and admin-ui/src/pages/index.ts
export { RootPage } from './pages/root';

The top-level layout component that wraps all other Admin UI pages. It provides the navigation shell, sidebar, and global context providers. Mount this as the layout route in React Router and nest all other pages inside it.

Working examples

Scenario - Mounting Admin UI pages in an existing React Router app

You have a React + React Router v6 app and want to embed the Graphweaver Admin UI pages alongside your own routes without running a separate SPA.

import { createBrowserRouter, RouterProvider, Outlet } from 'react-router-dom';
import { ApolloClient, InMemoryCache, ApolloProvider } from '@apollo/client';
import { RootPage } from './graphweaver/admin-ui/src/pages/root';
import { ListPage } from './graphweaver/admin-ui/src/pages/list';
import { AnalyticsPage } from './graphweaver/admin-ui/src/pages/analytics';
import { PlaygroundPage } from './graphweaver/admin-ui/src/pages/playground';

const client = new ApolloClient({
  uri: import.meta.env.VITE_API_URL,
  cache: new InMemoryCache(),
});

const router = createBrowserRouter([
  {
    path: '/admin',
    element: (
      <ApolloProvider client={client}>
        <RootPage />
      </ApolloProvider>
    ),
    children: [
      { path: ':entity', element: <ListPage /> },
      { path: 'analytics', element: <AnalyticsPage /> },
      { path: 'playground', element: <PlaygroundPage /> },
    ],
  },
]);

export default function App() {
  return <RouterProvider router={router} />;
}

Scenario - Standalone analytics dashboard

You want only the analytics view embedded in an existing dashboard shell without the full Admin UI navigation.

import { ApolloClient, InMemoryCache, ApolloProvider } from '@apollo/client';
import { AnalyticsPage } from './graphweaver/admin-ui/src/pages/analytics';

const client = new ApolloClient({
  uri: 'https://api.example.com/graphql',
  cache: new InMemoryCache(),
});

export function DashboardShell() {
  return (
    <ApolloProvider client={client}>
      <div style={{ padding: '2rem' }}>
        <h1>Operations Overview</h1>
        <AnalyticsPage />
      </div>
    </ApolloProvider>
  );
}

Scenario - GraphQL Playground as a developer tool route

You want to expose a /dev/playground route in development builds only.

import { PlaygroundPage } from './graphweaver/admin-ui/src/pages/playground';
import { ApolloClient, InMemoryCache, ApolloProvider } from '@apollo/client';

const client = new ApolloClient({
  uri: import.meta.env.VITE_API_URL,
  cache: new InMemoryCache(),
});

export function DevToolsRoute() {
  if (import.meta.env.PROD) return <div>Not available in production.</div>;

  return (
    <ApolloProvider client={client}>
      <PlaygroundPage />
    </ApolloProvider>
  );
}

File walkthrough

• admin-ui/src/pages/index.ts - Barrel that re-exports all four page components (analytics, list, root, playground) as the single public entry point for the pages layer.
• admin-ui/src/pages/analytics/ - Analytics dashboard page: component.tsx holds the React component, graphql.ts holds the Apollo query definitions, styles.module.css scopes CSS.
• admin-ui/src/pages/list/ - Entity list page: component.tsx renders paginated entity rows, graphql.ts contains the list query.
• admin-ui/src/pages/playground/ - GraphQL Playground page: component.tsx wraps the embedded IDE widget.
• admin-ui/src/pages/root/ - Root layout: component.tsx provides the nav shell and global providers, styles.module.css scopes layout CSS.
• admin-ui/src/main.tsx - SPA entry point; mounts the React root and the router.
• admin-ui/src/router.tsx - React Router configuration for the standalone Admin UI SPA.
• admin-ui/src/main.css / reset.css - Global and reset stylesheets for the Admin UI.
• admin-ui/@types/ - Ambient TypeScript declarations for auth, custom pages, CSV overrides, and Vite env variables.
• admin-ui-components/src/ - Shared component library (alerts, badges, assets, 404 page, custom fields).
• admin-ui-components/.storybook/ - Storybook configuration for developing and documenting components in isolation.

Common pitfalls and fixes

• Missing VITE_API_URL at build time - Vite inlines env vars at bundle time; if the variable is absent the Apollo Client URI will be undefined. Always provide .env or pass --mode explicitly.
• CSS Modules not resolving - The pages import *.module.css files; ensure your Vite or webpack config has CSS Modules enabled (modules: true in the css config section).
• React context missing for Apollo - Each page component expects an ApolloProvider ancestor. Mounting a page without it throws at runtime. Wrap at the router level, not per-page.
• React Router v5 vs v6 API mismatch - The pages use React Router v6 hooks (useParams, Outlet). Mixing v5 (Switch, useRouteMatch) will break routing silently.
• TypeScript jsx compiler option - The components use the new JSX transform (react-jsx). Without "jsx": "react-jsx" in tsconfig.json, compilation fails with "React is not defined".
• Storybook peer dep conflicts - admin-ui-components Storybook deps may conflict with your project's React version. Pin @storybook/* to the version declared in admin-ui-components/package.json or isolate it with a workspace.

Vibe-coding prompt template

I have purchased the Graphweaver Admin UI Pages block. The source code is in
the `source/` directory of this project, and the integration guide is in
`USAGE.md`.

The upstream package is `graphweaver` (domain: backend).

Please integrate these Admin UI pages into my existing TypeScript + React +
Vite project step by step:

1. Read `USAGE.md` fully before writing any code.
2. Copy the relevant packages from `source/` into the appropriate location in
   my project.
3. Update `tsconfig.json` and `vite.config.ts` with the required path aliases
   shown in `USAGE.md`.
4. Wire the `RootPage`, `ListPage`, `AnalyticsPage`, and `PlaygroundPage`
   components into my existing React Router v6 router.
5. Create or update the Apollo Client instance to point at my GraphQL API
   endpoint using the `VITE_API_URL` environment variable.
6. Confirm that CSS Modules are enabled in the Vite config.
7. Highlight any peer dependency conflicts and propose resolutions.

Only use imports and symbols that appear in `USAGE.md` and the source files.
Do not invent new APIs.

License and credit

Graphweaver is released under the MIT License. See the upstream repository for the full license text: https://github.com/exogee-technology/graphweaver.

This product’s unique contribution is clean room implementation of valuable code block into AVCP compatible standard.

The full install guide and integration prompts unlock after purchase.
